TRANSFORMERS
The information in this chapter is on the construction, theory, operation, and the various uses of transformers. Safety precautions to be observed by a person working with transformers are also discussed.
A TRANSFORMER is a device that transfers electrical energy from one circuit to another by electromagnetic induction (transformer action). The electrical energy is always transferred without a change in frequency, but may involve changes in magnitudes of voltage and current. Because a transformer works on the principle of electromagnetic induction, it must be used with an input source voltage that varies in amplitude. There are many types of power that fit this description; for ease of explanation and understanding, transformer action will be explained using an ac voltage as the input source.
In a preceding chapter you learned that alternating current has certain advantages over direct current. One important advantage is that when ac is used, the voltage and current levels can be increased or decreased by means of a transformer.
As you know, the amount of power used by the load of an electrical circuit is equal to the current in the load times the voltage across the load, or P = EI. If, for example, the load in an electrical circuit requires an input of 2 amperes at 10 volts (20 watts) and the source is capable of delivering only 1 ampere at 20 volts, the circuit could not normally be used with this particular source. However, if a transformer is connected between the source and the load, the voltage can be decreased (stepped down) to 10 volts and the current increased (stepped up) to 2 amperes. Notice in the above case that the power remains the same. That is, 20 volts times 1 ampere equals the same power as 10 volts times 2 amperes.
NOW WE WILL DESCRIBE ABOUT CURRENT TRANSFORMER&POTENTIAL TRANS FORMER:
OUR TEACHER TANBIR SIR QUESTION THROUGH TO US THAT
WHAT IS CURRENT TRANSFORMER AND POTENTIAL TRANSFORMER?
AND THEIR WORKING PRINCIPLE?
WHATEVER FIRST WE EXPLAIN CURRENT TRANSFORMER:
Current Transformer Design and Theory
If it were possible to have no core or wire losses at all, the calculation for the ratio between primary and secondary; equals dividing the primary current by the turns on the secondary equals the secondary current , then take the secondary current and multiplied it by the number of ohms of the burden resistor across the secondary, which would equal the voltage output across the secondary burden resistor.
Note: The maximum input current of a CT can be increased by varying the ohms of the burden resistor. Lowering the ohms of the burden resistor will increase the maximum input of the CT, but it lowers the resolution. Also, the accuracy of the output voltage depends on the accuracy of the burden resistor. The burden resistor should never be used for more than 55 % of its wattage capacity, and thermal concerns of the surrounding materials should be considered to prevent over heating damage. For circuits requiring very accurate outputs, the CT should only be used up to 50 % of saturation line of the core.
A current transformer is designed to provide a current in its secondary which is accurately proportional to the current flowing in its primary.
Current transformers are commonly used in electricity meters to facilitate the measurement of large currents which would be difficult to measure more directly.
Care must be taken that the secondary of a current transformer is not disconnected from its load while current is flowing in the primary as in this circumstance a very high voltage would be produced across the secondary.
Current transformers are often constructed with a single primary turn either as an insulated cable passing through a toroidal core, or else as a bar to which circuit conductors are connected.
How Does a Current Transformer Work?
A transformer is an electrical device that takes electricity of one voltage and changes it into another voltage. You'll see transformers at the top of utility poles and even changing the voltage in a toy train set.
Basically, a transformer changes electricity from high to low voltage using two properties of electricity. In an electric circuit, there is magnetism around it. Second, whenever a magnetic field changes (by moving or by changing strength) a voltage is made. Voltage is the measure of the strength or amount of electrons flowing through a wire.
If there's another wire close to an electric current that is changing strength, the current of electricity will also flow into that other wire as the magnetism changes.
A transformer takes in electricity at a higher voltage and lets it run through lots of coils wound around an iron core. Because the current is alternating, the magnetism in the core is also alternating. Also around the core is an output wire with fewer coils. The magnetism changing back and forth makes a current in the wire. Having fewer coils means less voltage. So the voltage is "stepped-dow
Transformers on the Electrical Grid
Let's look at the electricity that comes to your home. When electricity moves from a power plant it is put into a very high voltage to be able to travel long distances. The high voltage lines can be as high 155,000 to 765,000 volts to travel many hundreds of miles.
In order for your home or a store to use the electricity, it has to be at a lower voltage than on the long-distance lines. So, the electricity is "stepped-down to a lower level using a transformer. This lower voltage electricity is put into the local electric wires at a substation. The substation breaks the larger amount of power down into smaller pieces at lower voltage. It then is stepped down again and again.
Once smaller transformers take that voltage down to usually 7,200, the power leaves this substation.
In your neighborhood, a transformer on top of a utility pole, or one connected to underground wires, transforms the 7,200 volts into 220-240 volts. This is then sent into your home over three wires. The three wires go through the electric meter, which measures how much electricity you use. One of the three wires is the ground, and the other two are the positives.
Some of the electrical appliances in your home use the 220-240 volts. These are things like a water heater, stove and oven, or air conditioner. They have very special connections and plugs. Other devices, like your TV or computer only use one-half of the electricity -- 110-120 volts.
In a toy train set, the voltage is reduced even more from 110-120 and is changed from alternating current into direct current.
Some businesses use higher voltage power to run big machines. So, they don't need to have the voltage reduced as much.
POTENTIAL TRANSFORMER:
Potential Transformer is designed for monitoring single-phase and three-phase power line voltages in power metering applications.
The primary terminals can be connected either in line-to-line or in line-to-neutral configuration. Fused transformer models are designated by a suffix of "F" for one fuse or "FF" for two fuses.
A Potential Transformer is a special type of transformer that allows meters to take readings from electrical service connections with higher voltage (potential) than the meter is normally capable of handling without at potential transformer.
> A potential transformer is a type of transformer used by the electric
> ulitility companies for measuring the voltage on their high voltage
> power lines. These transformers are very well made, very robust,
> and have low losses. Two of these transformers used together can
> approach the performance of a pole or distribution transformer.
> Unfortunately, they can be hard to obtain.
Transformers can also be used in electrical instrumentation systems. Due to transformers' ability to step up or step down voltage and current, and the electrical isolation they provide, they can serve as a way of connecting electrical instrumentation to high-voltage, high current power systems. Suppose we wanted to accurately measure the voltage of a 13.8 kV power system (a very common power distribution voltage in American industry):
Direct measurement of high voltage by a voltmeter is a potential safety hazard.
Designing, installing, and maintaining a voltmeter capable of directly measuring 13,800 volts AC would be no easy task. The safety hazard alone of bringing 13.8 kV conductors into an instrument panel would be severe, not to mention the design of the voltmeter itself. However, by using a precision step-down transformer, we can reduce the 13.8 kV down to a safe level of voltage at a constant ratio, and isolate it from the instrument connections, adding an additional level of safety to the metering system:
Instrumentation application:"Potential transformer" precisely scales dangerous high voltage to a safe value applicable to a conventional voltmeter.
Now the voltmeter reads a precise fraction, or ratio, of the actual system voltage, its scale set to read as though it were measuring the voltage directly. The transformer keeps the instrument voltage at a safe level and electrically isolates it from the power system, so there is no direct connection between the power lines and the instrument or instrument wiring. When used in this capacity, the transformer is called a Potential Transformer, or simply PT.
Potential transformers are designed to provide as accurate a voltage step-down ratio as possible. To aid in precise voltage regulation, loading is kept to a minimum: the voltmeter is made to have high input impedance so as to draw as little current from the PT as possible. As you can see, a fuse has been connected in series with the PTs primary winding, for safety and ease of disconnecting the PT from the circuit.
A standard secondary voltage for a PT is 120 volts AC, for full-rated power line voltage. The standard voltmeter range to accompany a PT is 150 volts, full-scale. PTs with custom winding ratios can be manufactured to suit any application. This lends itself well to industry standardization of the actual voltmeter instruments themselves, since the PT will be sized to step the system voltage down to this standard instrument level.
